FEATURES:
Enables single-pass cutting of 89 mm (3-1/2″) 4x materials
Large cutting capacity (97 mm (3-13/16″) at 90° with 260 mm (10-1/4″) blade, 101 mm (4″) at 90° with 270 mm (10-5/8″) blade) and bevel capacity (0°-50°)
Magnesium components create a lightweight saw that is well balanced and job site tough
Fine parallel adjustment of the base plate to the saw blade
Compatible with optional guide rail for increased maneuverability
Powerful 2,100 W motor delivers 4,300 RPM
Rigid aluminum base provides smooth cutting thanks to its lightness, toughness and good bend resistance
Rear angular guide for smooth and precise adjustment of bevel angle
Dust nozzle is attachable for connecting to vacuum cleaner
Handy guide rule allows operator to do extra-accurate straight cuts
Soft grip provides increased comfort on the job
Make quick, one-handed adjustments using large, rubberized levers
Flat motor housing design for stability when changing the blade
Rear dust port exhausts sawdust away from operator for clean and comfortable operation
Onboard hex wrench for fast and easy blade changes
Two-stage safety trigger switch prevents accidental start up (For tool with Lock-off button)
Lock-on button for continuous use operation (For tool with Lock-on button)
Conveniently located shaft lock for easy blade replacement
Externally accessible brushes for easy serviceability. Double insulated
SPECIFICATIONS:
Continuous rating input
2,000W
Blade Diameter
260 / 270 mm (10-1/4″ / 10-5/8″)
Max Cutting Capacity
90°: 97 / 101 mm (3-13/16″ / 4″)
45°: 68 / 71 mm (2-11/16″ / 2-13/16″)
50°: 61 / 63 mm (2-3/8″ / 2-1/2″)
No Load Speed (RPM)
4,300
Vibration Level
Cutting Wood: 2.5 m/s² or less
Vibration K Factor
Cutting Wood: 1.5 m/s²
Sound Pressure Level
94 dB(A)
Sound Power Level
105 dB(A)
Noise K Factor
3 dB(A)
Dimensions (L x W x H)
418x273x324 mm (16-1/2″x10-3/4″x12-3/4″)
Net weight
6.9 kg (15.2 lbs.)
Power supply cord
2.5 m (8.2 ft.)
