Features
COMFORT – Anti-Vibration Technology is an internal counterbalance system that greatly reduces vibration.
PERFORMANCE – Integrated damper spring is engineered to absorb impact vibrations from the drill bit
CONVENIENCE – L.E.D. light illuminates drilling surface for more productivity
DURABILITY – Recessed hammer function selector located below gear housing
Re-located operating mode lever for increased protection and durability; enables switch to rotate both left and right
Improved bit guide for increased bit stability during drilling applications
Easy-to-grip handle gives maximum power thrust and provides a sure and comfortable grip in any operation; overhead application, drilling with palm-up or palm-down grip
Soft grip provides more comfort and control
3 Modes
SPECIFICATIONS:
Continuous rating input
800W
Impact Energy
EPTA-Procedure 05/2009: 2.4 J
Capacity
Concrete: 26 mm (1″)
Core Bit: 68 mm (2-11/16″)
Diamond Core Bit (Dry Type): 80 mm (3-1/8″)
Steel: 13 mm (1/2″)
Wood: 32 mm (1-1/4″)
Blows Per Minute (BPM)
0 – 4,600
No Load Speed (RPM)
0 – 1,200
Sound Pressure Level
90 dB(A)
Sound Power Level
101 dB(A)
Vibration Level
Hammer Drilling Into Concrete: 12.0 m/s²
Dimensions (L x W x H)
361x77x209 mm (14-1/4″x3″x8-1/4″)
Net weight
2.9 – 3.4 kg (6.4 – 7.4 lbs)
Power supply cord
2.5 m (8.2 ft)
Bit Type
Accepts SDS-PLUS
Lifetime Service Warranty
