FEATURES:
Delivers 25% more drilling, driving and fastening speed than previous model
Aluminum gear housing creates an impression of rigidity and luxuriousness
Compact and ergonomic design at only 172 mm (6-3/4″) long
Variable 2-speed (0-500 & 0-2,000 RPM) for a wide range of drilling and fastening applications
Built-in twin LED lights with pre-glow and afterglow functions illuminate the work area
BL motor delivers 60 N·m (530 in.lbs.) of max torque
BL motor is electronically controlled to optimize battery energy use for up to 50% longer run time per charge
BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
BL motor efficiently uses energy to match torque and RPM to the changing demands of the application
Lightweight for reduced operator fatigue
21 Clutch settings and drill mode for added fastening control
Best possible ergonomic handle with soft grip for driver-drill applications
All metal gear construction for extra-high transmission durability
Extreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
Convenient 13 mm (1/2″) keyless chuck for quick bit changes
Battery protection circuit protects against overloading, over-discharging and over-heating
Mechanical 2-speed gearing; High speed mode for speedy drilling in light duty applications; Low speed mode for heavy duty applications requiring high torque
Electric brake for maximum productivity and increased operator safety
Reversing switch is conveniently located. Durable, reversible belt clip convenient for temporary tool hanging
SPECIFICATIONS:
Capacity
Steel / Wood: 13 / 38 mm (1/2 / 1-1/2″)
Chuck Capacity
1.5 – 13 mm (1/16 – 1/2″)
No Load Speed (RPM)
High / Low: 0 – 2,000 / 0 – 500
Max Fastening Torque
Hard / Soft: 54 / 30 N·m (480 / 270 in.lbs.)
Max Lock Torque
60 N·m (530 in.lbs.)
Vibration Level
Drilling into Metal: 2.5 m/s² or less
Vibration K Factor
Drilling into Metal: 1.5 m/s²
Sound Pressure Level
76 dB(A)
Sound Power Level
N/A dB(A)
Noise K Factor
3 dB(A)
Dimensions (L x W x H)
172 x 79 x 261 mm (6-3/4 x 3-1/8 x 10-1/4″)
Net weight
1.5 – 1.8 kg (3.3 – 4.0 lbs.)
