Positioning
Compact, precise and powerful – The qualities of a champion
User benefit
Powerful 350 W motor for tough applications
4000 rpm no-load speed for accurate drilling of small diameters
All ball bearing construction for long lifetime
Compact, precise and powerful – The qualities of a champion
Rated input power
350 W
Drilling diameter in wood
15 mm
Drilling diameter in steel
6.5 mm
Technical data
Rated input power
350 W
No-load speed, 1st gear
0 – 4,000 rpm
Power output
136 W
Weight
1.1 kg
Rated speed
3,116 rpm
Rated torque
12.3 Nm
Drill spindle connecting thread
3/8″-24 UNF
Chuck capacity, min./max.
0.5 mm
Bit holder
3/8″-24 UNF
Tool dimensions (width)
33 mm
Tool dimensions (length)
210 mm
Tool dimensions (height)
190 mm
Drilling range
Drilling diameter in aluminium
6 mm
Drilling diameter in wood
15 mm
Drilling diameter in steel
6.5 mm
Noise/vibration information
Noise level
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
