Powerful 1500 watt at low vibration
Peak performance in Drilling and Chiseling
Three-way Vibration Control System, Turbo Power Function
Turbo Function to utilize power, which is used for rotation in drilling mode, additionally for chiseling
Best drilling and chiseling performance in class due to newly developed impact mechanism with 12,5 Joule impact energy and 1.500 Watt motor
Low vibrations due to: (1) AV-impact mechanism (2) decoupled main handle (3) tuned mass damper integrated in aluminium cover
Auto lock-on function in chiseling mode
Constant electronic with absolute speed dial with 6 positions
Drilling mode: Switch does not lock on. Important safety requirement
Chiseling mode: Switch locks on automatically. Released manually by pulling the lower trigger.
Reduced creation of vibration within impact mechanism (longer air cushion)
SDS Max
Technical data
Rated input power
1,500 W
Impact energy (according to EPTA 05/2016)
12.5 J
Impact rate at rated speed
1,380 – 2,760 bpm
Rated speed
150 – 305 rpm
Weight
8,9 kg
Tool dimensions (width)
116 mm
Tool dimensions (length)
540 mm
Tool dimensions (height)
310 mm
Tool holder
SDS max
Product category subdivision
Rotary Hammer with SDS max
Drilling range
Hammer drilling diameter range in concrete
12 – 45 mm
Recommended drilling diameter range in concrete
32 – 40 mm
Drilling dia. concrete, breakthrough drill bits
16 – 45 mm
Drilling diameter in concrete with core cutters
0 – 120 mm
Noise/vibration information
Noise level
The A-rated noise level of the power tool is typically as follows: Sound pressure level 96 dB(A); Sound power level 107 dB(A). Uncertainty K= 3 dB.
